Naval Group: French Navy minehunter gets 3D-printed propeller

Naval Group has equipped FS Andromede (M643), the French Navy’s Eridan-class minehunter, with a 3D-printed propeller.

Naval Group

The French defence contractor manufactured this new-generation propeller thanks to a metal 3D printing process. Mounted on the tripartite minehunter, the propeller will now accompany the ship in all of its operational missions.

View on Twitter.

With its 2.5-metre span supported by five 200-kg blades, the equipment left the workshops of the Naval Group site of Nantes-Indret in October 2020 for the site of Brest in order to be mounted on the propeller shaft. As part of its major technical stop, the assembly was transferred to the submarine base to be mounted on the intermediate shaft of the Andromède in November.

Sea trials were then performed successfully at the end of December.

A world first for military on-board innovation

“Nearly three years of R&D – carried out by the Technical and Innovation Department in cooperation with the Ecole Centrale de Nantes within the framework of the LabCom Joint Laboratory of Maritime Technology – went into the development of the deposition process of metal wire fusion,” Emmanuel Chol, Director of the Nantes-Indret site, explained.

“Today, we witness a world first. It is the largest metal 3D-printed thruster ever to have been manufactured and the first propeller resulting from this technology, embarked on board a military ship and manufactured for use beyond just sea trials.”

The harsh conditions in which ships are used warrant the need to meet strict requirements such as the corrosion, fatigue, shock resistance, etc. Naval Group worked together with Bureau Véritas throughout the process to present its technical justification file in order to allow the Fleet Support Services (SSF) and the French Defence Procurement Agency (DGA) to authorise the trial of the blades produced on a military ship in normal operating conditions. The blades received certification from Bureau Véritas.

€7 million investment in metal 3D printing in 2021

For Eric Balufin, Director of the Naval Group site of Brest, the assembly of the 3D-printed propeller “shows great promise for the future”.

This new technology will enable us to considerably reduce technical constraints, and therefore allow for new manufacturing solutions for complex geometrical shapes which cannot be produced through conventional processes. It will also enable us to greatly reduce production time and consequently in-service support.”

Photo: Naval Group

This propeller is the first step, Naval Group said. A new development phase will begin, aimed at revamping the detailed design of other parts so that they benefit from 3D printing. For example, 3D-printed production of thrusters will provide ships with greater efficacy at sea — increased thrust efficiency, stealth and lightening.
